LEDENET CCT RGB 3CH Channel High Speed Power Amplifier 30A Data Signal Repeater DC12V/24V for 2PIN 3PIN 4PIN CCT RGB LED Strip Lights Module Lights

Description

• High Power Output: Drive your lighting projects with robust 10A per channel and a total 30A max load.Total Output of Current: 30A. Output: 3 circuit. Output power: max 360W(12V), max 720W(24V).Effortlessly power longer LED strip lights and prevent signal loss over long distances.
• Wide Voltage Compatibility: Versatile DC 12-24V input seamlessly integrates with common low-voltage LED strip lights systems, offering flexible power connection options for easy installation.
• Perfect Signal Synchronization: Features PWM signal input for synchronized high-power output. Cascade multiple units for limitless expansion and perfectly coordinated lighting effects.
• Used for LED Strips: Used for CCT, RGB DC12-24V LED strip lights. 3pin(V+ CW WW) 4pin(+ R G B) LED strips.The amplifier is common anode.
• NOTE: Please note that it is only suitable for PWM LED Strip without IC. It can not work with addressable IC chip LED strip lights.

Function
Amplify the red, green, blue three group signal of 3 channel controller, improve the system with load capacity, and has minimal delay, but can keep synchronism in cascade.
The outlet should be connected correctly according to the color shown in the wiring diagram.
Can't be wrong attached, in order to avoid short-circuit.

Specification
Working temperature: -20~60
Input voltage: DC12-24V
Signal voltage: DC 12V-24V
Input signal: RGB common anode PWM dimming signal
Dimension: L145*W76.8*H20.6mm
Output: 3 channel
Connection mode: Common anode
Output current: max 10A x 3CH
Output power: max 360W(12V), max 720W(24V)
Delay time: 20NS

Package included:
1pc * RGB high speed power Amplifier
