AURSINC ZK09-UM LNA Low Noise Amplifier, 100kHz-10GHz, Ultra-broadband, Low Noise, Good Flatness, 21dB@2GHz Gain, USB Interface Powered, for TinySA Ultra, RF & Software Defined Radio (SDR)

AURSINC

AURSINC ZK09-UM LNA Low Noise Amplifier, 100kHz-10GHz, Ultra-broadband, Low Noise, Good Flatness, 21dB@2GHz Gain, USB Interface Powered, for TinySA Ultra, RF & Software Defined Radio (SDR)

SG$92.44 SG$154.07
Buying Bulk?
  • Order within to get between
  • Tracked Shipping on All Orders
  • 14-Day Returns
  • Secure Payments
  • 24/7 Customer Support
Buying Bulk?

Description

  • [High Performance] Broadband, Low Noise. Frequency: 100kHz-10GHz, Gain: 21.5dB@10MHZ / 21dB@2GHz / 17.5dB@6GHz, OP1dB: 13dBm Typ. Can be used to replace ADM-8095 ADM-8625 modules
  • [USB Interface Powered] ZK09-UM is USB interface powered RF low noise amplifier with convenient power supply interface, broadband, low noise. Supply Current: 52mAOn-chip bias, user can adjust the bias resistor to reduce the current
  • [Reduce Noise Floor] Powered by USB type-C interface, and the built-in high PSRR LDO can effectively reduce the power noise, which effectively reduces the noise floor compared with other vendor's USB direct-feed modules
  • [Application] Recommended for use as tinySA ULTRA 5.8GHz preamplifier. Since the LNA in tinySA ULTRA is effective only below 3.5GHz, adding an LNA can enhance high-frequency sensitivity
  • [Note] The ZK0X-UM LNA module has a very compact design and uses a system shield case, which may rust if exposed to moisture. Please pay attention to moisture protection when using outdoors
  • Please note that when testing the LNA, do not apply excessive power or signal, as this may lead to saturation or even damage to the device
